Eccentric reducing socket malleable cast iron galvanised

  Datasheet (PDF)

The Georg Fischer eccentric reducing socket 260 in galvanised malleable cast iron provides robust, dimensionally stable diameter transitions for threaded pipe systems requiring asymmetric alignment. Operating with an engineered offset centerline axis (dimension m), this female-threaded fitting allows horizontal pipework to maintain a continuous level bottom line for complete fluid drainage or a flat top line to prevent the accumulation of air pockets and entrapped gases. This eccentric geometry is critical in industrial fluid processing, steam and condensate networks, heating, cooling, compressed air, and gas distribution systems, where avoiding liquid pooling or gas blockage is vital for hydraulic balance and operational safety. Manufactured from premium decarburised annealed whiteheart malleable cast iron EN-GJMW-400-5 in compliance with EN 10242 Design Symbol A, the fitting body delivers superior tensile endurance, structural elasticity, and outstanding resistance to mechanical stress and torsional loads during wrench tightening. Long-term corrosion protection is achieved through a thorough hot-dip galvanising process, producing durable iron-zinc diffusion layers covered by a pure zinc exterior with an average thickness exceeding 70 micrometres, making the fitting fully compliant with strict hygienic standards for potable water installations. Both connection ports feature precision parallel internal pipe threads (Rp) according to EN 10226-1 and ISO 7-1, ensuring tight, reliable sealing along the threads when engaged with matching taper male threads and appropriate jointing media. Rated for operating pressures up to 25 bar between minus 20 degrees Celsius and 120 degrees Celsius, and up to 20 bar at 300 degrees Celsius, the component integrates standardised z-dimensions to streamline layout planning, calculation, and pipe prefabrication.
