COOL-FIT 2.0/4.0 Adaptor fitting PE100/SS

COOL-FIT 2.0/4.0 Adaptor fitting PE100/SS

Material: PE100 / SS PN: 16 Bar

  Datasheet (PDF)

The Georg Fischer COOL-FIT 2.0/4.0 PE100 to stainless steel adaptor fitting provides a demountable transition between pre-insulated polyethylene cooling piping and threaded mechanical equipment. Designed for commercial HVAC, data centers, and process cooling loops, it joins a metric SDR11 PE100 spigot to a 316L stainless steel cylindrical female G-thread union nut. Rated for PN16 pressure across d32 to d63 mm, it delivers permanent tightness and condensation-free reliability.

Technical specifications

This hybrid transition fitting is engineered for continuous chilled-water operation under nominal working pressures up to 16 bar. It maintains fluid integrity within a certified operating temperature range of 0 degrees Celsius to +60 degrees Celsius.

  • Nominal pressure rating: PN16 (16 bar) across the complete d32 to d63 mm range
  • Operating temperature range: 0 degrees Celsius to +60 degrees Celsius
  • Pipe standard dimension ratio: PE100 SDR11 metric spigot
  • Mechanical connection: Cylindrical female thread loose union nut according to ISO 228 (G)
  • Sealing element: Factory-supplied flat EPDM elastomer gasket

Materials and standards

The adaptor combines virgin PE100 polyethylene with acid-resistant 1.4404 (AISI 316L) stainless steel to prevent galvanic corrosion at the plastic-to-metal boundary. All component dimensions and threaded interfaces comply fully with EN ISO 15494 and ISO 228 manufacturing standards.

High-grade 316L stainless steel provides superior resistance against aggressive glycol mixtures and harsh ambient conditions, while the halogen-free construction ensures zero ozone depletion potential. The integrated EPDM gasket exhibits excellent resilience against thermal cycling and pressure fluctuations, guaranteeing leak-free operational safety across secondary refrigeration and industrial cooling infrastructure.

Installation and jointing

Connection to the pre-insulated pipework is achieved by electrofusion welding using standard COOL-FIT couplers or conventional butt fusion. The mechanical stainless steel loose nut allows rapid, twist-free attachment directly to male-threaded valves, chillers, and manifold headers.

Because the union nut rotates freely during assembly, installers can torque the mechanical connection without imparting torsional stress to the polyethylene piping. The bare PE100 spigot end fits standard peeling and electrofusion preparation protocols, while post-insulation half-shells from the COOL-FIT system seal seamlessly over the completed joint to prevent condensation.

  Datasheet (PDF)

The Georg Fischer COOL-FIT 2.0/4.0 PE100 to stainless steel adaptor fitting provides a demountable transition between pre-insulated polyethylene cooling piping and threaded mechanical equipment. Designed for commercial HVAC, data centers, and process cooling loops, it joins a metric SDR11 PE100 spigot to a 316L stainless steel cylindrical female G-thread union nut. Rated for PN16 pressure across d32 to d63 mm, it delivers permanent tightness and condensation-free reliability.

Technical specifications

This hybrid transition fitting is engineered for continuous chilled-water operation under nominal working pressures up to 16 bar. It maintains fluid integrity within a certified operating temperature range of 0 degrees Celsius to +60 degrees Celsius.

  • Nominal pressure rating: PN16 (16 bar) across the complete d32 to d63 mm range
  • Operating temperature range: 0 degrees Celsius to +60 degrees Celsius
  • Pipe standard dimension ratio: PE100 SDR11 metric spigot
  • Mechanical connection: Cylindrical female thread loose union nut according to ISO 228 (G)
  • Sealing element: Factory-supplied flat EPDM elastomer gasket

Materials and standards

The adaptor combines virgin PE100 polyethylene with acid-resistant 1.4404 (AISI 316L) stainless steel to prevent galvanic corrosion at the plastic-to-metal boundary. All component dimensions and threaded interfaces comply fully with EN ISO 15494 and ISO 228 manufacturing standards.

High-grade 316L stainless steel provides superior resistance against aggressive glycol mixtures and harsh ambient conditions, while the halogen-free construction ensures zero ozone depletion potential. The integrated EPDM gasket exhibits excellent resilience against thermal cycling and pressure fluctuations, guaranteeing leak-free operational safety across secondary refrigeration and industrial cooling infrastructure.

Installation and jointing

Connection to the pre-insulated pipework is achieved by electrofusion welding using standard COOL-FIT couplers or conventional butt fusion. The mechanical stainless steel loose nut allows rapid, twist-free attachment directly to male-threaded valves, chillers, and manifold headers.

Because the union nut rotates freely during assembly, installers can torque the mechanical connection without imparting torsional stress to the polyethylene piping. The bare PE100 spigot end fits standard peeling and electrofusion preparation protocols, while post-insulation half-shells from the COOL-FIT system seal seamlessly over the completed joint to prevent condensation.

Variants, prices and availability
Size SKU Property U.M.
Price
incl. 21% VAT
Availability Add To Cart
D 32 mm
Thread 1/2"
738940308
Material: PE100 / SS
PN: 16 Bar
pcs On Request
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
D 32 mm
Thread 3/4"
738940318
Material: PE100 / SS
PN: 16 Bar
pcs On Request
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
D 32 mm
Thread 1"
738940328
Material: PE100 / SS
PN: 16 Bar
pcs On Request
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
D 40 mm
Thread 1 1/4"
738940309
Material: PE100 / SS
PN: 16 Bar
pcs On Request
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
D 50 mm
Thread 1 1/2"
738940310
Material: PE100 / SS
PN: 16 Bar
pcs On Request
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
D 63 mm
Thread 2"
738940311
Material: PE100 / SS
PN: 16 Bar
pcs On Request
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
incl. 21% VAT
SKU: 738940308
D: 32 mm
Thread: 1/2"
Ships in 24 hours
On Request / pcs
SKU: 738940318
D: 32 mm
Thread: 3/4"
Ships in 24 hours
On Request / pcs
SKU: 738940328
D: 32 mm
Thread: 1"
Ships in 24 hours
On Request / pcs
SKU: 738940309
D: 40 mm
Thread: 1 1/4"
Ships in 24 hours
On Request / pcs
SKU: 738940310
D: 50 mm
Thread: 1 1/2"
Ships in 24 hours
On Request / pcs
SKU: 738940311
D: 63 mm
Thread: 2"
Ships in 24 hours
On Request / pcs
