ABS Male Threaded Plug R PN10 1/2" - 1"

ABS Male Threaded Plug R PN10 1/2" - 1"

Material: ABS PN: 10 Bar

  Datasheet (PDF) |   Product Range | Instructional Video

The Georg Fischer ABS male threaded plug R is an industrial pipe closure engineered to provide a secure, leak-tight termination in pressurized plastic piping networks. Designed for process engineers and mechanical contractors, this fitting features an external BSP taper male thread R rated for operating pressures up to PN10 (10 bar at 20 degrees Celsius) across nominal thread sizes from 1/2" to 1".

Technical specifications

This threaded plug provides dependable mechanical strength and pressure containment for isolating inactive manifold branches or terminating process lines. Each fitting is manufactured with precision-moulded external threads that ensure dimensional stability and repeatable engagement across industrial installations.

  • Material: Acrylonitrile Butadiene Styrene (ABS)
  • Nominal pressure: PN10 (10 bar at 20 degrees Celsius)
  • Connection type: External taper thread R (male BSP taper)
  • Size range: Thread dimensions 1/2", 3/4", and 1"
  • Thread depth s: 27 mm (1/2"), 36 mm (3/4"), and 41 mm (1")
  • Corrosion resistance: Fully immune to rust, scaling, and galvanic degradation

Installation and jointing

Threaded ABS connections require specific chemical compatibility measures to safeguard joint integrity and prevent stress cracking. Assemblers must strictly avoid conventional pipe sealing pastes, hemp, or thread compounds that contain aggressive solvents and plasticisers detrimental to thermoplastic polymers.

To achieve an effective hydraulic seal, installers must wrap the external taper thread exclusively with approved virgin PTFE sealing tape. Threads should be hand-tightened into the mating female fitting and finished with a calibrated strap wrench to avoid excessive circumferential stress, ensuring a long-lasting, maintenance-free seal in continuous duty.

Applications

Engineered from high-ductility ABS, this closure plug maintains outstanding impact resistance at sub-zero temperatures where conventional rigid thermoplastics become brittle. Its smooth bore and non-toxic formulation prevent limescale build-up and maintain high purity in fluid conveyance systems.

Typical deployment areas include chilled water loops, industrial cooling water circuits, water treatment facilities, marine engineering systems, and potable water distribution networks. As an authorised Georg Fischer distributor, BigWeld supplies genuine GF Piping Systems components across Europe, supporting industrial plants and contractors with fully certified thermoplastic piping solutions.

  Datasheet (PDF) |   Product Range | Instructional Video

The Georg Fischer ABS male threaded plug R is an industrial pipe closure engineered to provide a secure, leak-tight termination in pressurized plastic piping networks. Designed for process engineers and mechanical contractors, this fitting features an external BSP taper male thread R rated for operating pressures up to PN10 (10 bar at 20 degrees Celsius) across nominal thread sizes from 1/2" to 1".

Technical specifications

This threaded plug provides dependable mechanical strength and pressure containment for isolating inactive manifold branches or terminating process lines. Each fitting is manufactured with precision-moulded external threads that ensure dimensional stability and repeatable engagement across industrial installations.

  • Material: Acrylonitrile Butadiene Styrene (ABS)
  • Nominal pressure: PN10 (10 bar at 20 degrees Celsius)
  • Connection type: External taper thread R (male BSP taper)
  • Size range: Thread dimensions 1/2", 3/4", and 1"
  • Thread depth s: 27 mm (1/2"), 36 mm (3/4"), and 41 mm (1")
  • Corrosion resistance: Fully immune to rust, scaling, and galvanic degradation

Installation and jointing

Threaded ABS connections require specific chemical compatibility measures to safeguard joint integrity and prevent stress cracking. Assemblers must strictly avoid conventional pipe sealing pastes, hemp, or thread compounds that contain aggressive solvents and plasticisers detrimental to thermoplastic polymers.

To achieve an effective hydraulic seal, installers must wrap the external taper thread exclusively with approved virgin PTFE sealing tape. Threads should be hand-tightened into the mating female fitting and finished with a calibrated strap wrench to avoid excessive circumferential stress, ensuring a long-lasting, maintenance-free seal in continuous duty.

Applications

Engineered from high-ductility ABS, this closure plug maintains outstanding impact resistance at sub-zero temperatures where conventional rigid thermoplastics become brittle. Its smooth bore and non-toxic formulation prevent limescale build-up and maintain high purity in fluid conveyance systems.

Typical deployment areas include chilled water loops, industrial cooling water circuits, water treatment facilities, marine engineering systems, and potable water distribution networks. As an authorised Georg Fischer distributor, BigWeld supplies genuine GF Piping Systems components across Europe, supporting industrial plants and contractors with fully certified thermoplastic piping solutions.

Variants, prices and availability
Size SKU Property U.M.
Price
incl. 21% VAT
Availability Add To Cart
Thread 1/2"
729961906
Material: ABS
PN: 10 Bar
pcs €8.52
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
Thread 3/4"
729961907
Material: ABS
PN: 10 Bar
pcs €10.68
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
Thread 1"
729961908
Material: ABS
PN: 10 Bar
pcs €13.06
Ships in 24 hours Ships in 7-10 days Ships in 10-15 days Max stock reached Please call
incl. 21% VAT
SKU: 729961906
Thread: 1/2"
Ships in 24 hours
€8.52 / pcs
SKU: 729961907
Thread: 3/4"
Ships in 24 hours
€10.68 / pcs
SKU: 729961908
Thread: 1"
Ships in 24 hours
€13.06 / pcs
